Gold film reflector
Keywords:
Gold film reflector
Category:
Hotline:
Gold film reflector
In high-speed transmission systems, mirrors or total reflectors are used as rear mirrors and folding mirrors within the laser cavity, while outside the cavity they act as beam return mirrors. Silicon, copper, and molybdenum are generally used as substrates. Silicon is a commonly used substrate for coated reflective mirrors, offering advantages such as low cost, durability, and stable thermal properties. Due to its high thermal conductivity, copper is typically used in high-power CO2 lasers. Molybdenum boasts extremely high surface strength, enabling operation in harsh environments with a long lifespan, high power handling capacity, and a non-coated, wipe-resistant surface.
Product Parameters
| Model | Material | Diameter (mm) | Thickness (mm) | Reflectivity |
| American 26 | Silicon | 25 | 3 | > 99.8 |
| American 26 | Silicon | 30 | 3 | > 99.8 |
| Gold-coated Silicon | Silicon | 20 | 3 | > 99.6 |
| Gold-coated Silicon | Silicon | 25 | 3 | > 99.6 |
| Gold-coated Silicon | Silicon | 30 | 3 | > 99.6 |
| Dielectric-coated Silicon | Silicon | 20 | 3 | > 99.6 |
| Dielectric-coated Silicon | Silicon | 25 | 3 | > 99.6 |
| Molybdenum Reflector | Molybdenum | 20 | 3 | > 97 |
| Molybdenum Reflector | Molybdenum | 25 | 3 | > 97 |
| Molybdenum Reflector | Molybdenum | 30 | 3 | > 97 |
